发货地: 上海

品牌 GIANT

型号 P430A

工作压力 0-220BAR

柱塞直径 18(mm)

重量 17(kg)

转速 1450(r/m)

柱塞数 3

材质 铸铜

驱动方式 电动

用途 增压泵

类型 高压柱塞泵

泵轴位置 卧式

流量 1.5(m3/h)

参数：最大压力:220BAR (3200PSI)

流量：25L/MIN (6.7GPM)

转速：1450RPM

配套功率范围：7.5-11KW

柱塞直径：18MM

行程：24MM

进口螺纹：G3/4

出口螺纹：G3/4

泵头材质：黄铜

重量：17KGS

高压泵主要用于配套工业清洗设备、冲洗生产线、高压清洗机等。

可连续24小时运转，免维护。

Model P430A

Volume ................................................................................................... Up to 7.5 GPM

Discharge Pressure ................................................................................. Up to 3200 PSI

Inlet Pressure .......................................................................................... -4.35 to 145 PSI

Stroke ..................................................................................................... 24mm

RPM....................................................................................................... Up to 1450 RPM

Plunger Diameter .................................................................................... 18mm

Temperature of Pumped Fluids ............................................................... Up to 160 oF

Inlet Ports ............................................................................................... (2) 3/4" BSP

Discharge Ports ...................................................................................... (2) 3/4" BSP

Shaft Rotation ............................................................................. Top of pulley towards manifold

Crankshaft Diameter ............................................................................... 28mm

Key Width .............................................................................................. 8mm

Shaft Mounting ....................................................................................... Either side1

Weight .................................................................................................... 36lbs. 11oz.

Crankcase capacity ................................................................................. 30fl.oz.

Volumetric Efficiency @ 1450 ................................................................ 0.95

Mechanical Efficiency @ 1450 ............................................................... 0.82
